1.2L REVOTRON ENGINE
44
Air Filter, Snorkel and Blow-by pipe
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Air Filter Element
2 Air Filter Assy.
3 Hex Flange Screw M6x28 (2 Qty)
1.0
4 Separator Clamp
5 Hex Flange Screw M6x12 (2 Qty)
6 Bracket Hose Blow-By
7 Blow-by Hose Primary
8 Spring. Band Clamp 17Dx12W (2 Qty)
9 Washer (2 Qty)
10 Rubber Grommet (2 Qty)
11 Spacer (2 Qty)
12 Blow-by Hose Secondary
13 Hose Clamp (23 Dia.) (2 Qty)
14 Hose Clamp (70 Dia.) (2 Qty)
0.68
15 Hose, Air Filter To Tc
16 Hex Flange Screw M6x14
1.0
17 Bracket, Snorkel
18 Hex Flange Bolt M8x25 (2 Qty)
1.0
19 Washer (2 Qty)
20 Resonator Pipe
21 Hose Clamp (70 Dia.)
22 Hose, Resonator Box To Intake Pipe
23 Hex Flange Screw M6x12 (2 Qty)
1.0
24 Bracket, Air Filter
25 Rubber Grommet (On Engine For Air Filter)
26 Air filter top cover screw M5x20 (5 Qty.)
0.3-0.55
