BODY

24

1.4.9. FRONT DOOR TRIMS

REMOVAL

1. Open the Door.

2. Pull out Pull cup Cap.

3. Remove mounting screw below Pull cup Cap.

4. Insert wedge pin and remove window-winding

switch from door pull outer.

5. Disconnect the window winding connection

and remove the switch.

6. Remove inner handle screw cap.

7.

Loosen and remove the mounting screw of

inner handle.

8. Insert plastic wedge pin and remove the door

trim.
