NEXON

GENERAL

1.4 VEHICLE JACKING AND LIFTING POINTS:

Make sure you follow the manufacturer’s

instructions while lifting the car on two post lift.

• Always ensure vehicle balance in service

while applying two post lift to under body.

• Care should be taken that the two post lift arm

is not in contact with the bracket, brake or fuel

pipes etc.

• Before servicing, make sure to lock the lift

after the vehicle is lifted up.

• Following fig shows the front and the rear

jacking points by two post lift

JACKING POINTS

Front and Rear jacking point

USING THE FLOOR JACK:

• Use the jacks at the locations as shown in the

below.

• Do not apply the jack against any part which

may get deformed.

• If front end or rear end of the vehicle is to be

jacked ensure the wheels on ground and the

parking brake is applied.

Front jacking point

Rear jacking point
