NEXON

FATC

2. BLOWER SPEED CONTROL KNOB

a. Rotate the knob clockwise to increase the blower

speed up to MAX (Speed 7), whereas

anticlockwise would reduce the speed up to Min

(Speed 1).

Blower control shall indicate the control of the quan-

tity of airflow, which is accomplished by controlling

the speed of the blower fan. The Blower control shall

happen either manually or through an automatic

climate control algorithm

3. ECON MODE

During ECON AC operation, the system automatically

cuts off compressor at a higher temperature than

normal AC. The operation can be used during mild

weather conditions for better fuel efficiency. Comfort

level may be compromised during this operation.

4. MAX DEFROST BUTTON

a. This button directs the main airflow towards

windscreen for faster defrosting (It also overrides

any mode selection you may have made.)

b. When you turn off the button, the system returns

to its former settings.

On pressing this button the

LED is illuminated indicating air distribution to

max defrost mode is ON.

CAUTIONS

For your safety make sure you have a clear view

through all the windows before driving

5. REAR WINDOW DEMISTER – HRW (IF

APPLICABLE)

This button turns the rear window demister ON or

OFF. The system automatically deactivates. On

pressing this button, the LED is illuminated indicating

defogging of the rear window.

Rear demister/defogger will work only when Engine is

ON.

6. FRESH AIR / RECIRCULATION BUTTON

a. When the user pushes the Fresh air \ Recirculation

button , the LED turns ON, the air inlet door flap

shall move to the RECIRCULATION position and

air from the vehicle’s interior is sent throughout the

system.

b. When the user pushes the Fresh \ Recirculation

button and the LED turns off, air is brought in from

outside of the vehicle (fresh mode). Whenever

discomfort is felt, switch to fresh air mode.

c. The Fresh \ Recirculation control shall switch to

Auto operation immediately after the user presses

the Auto button. The Climate control algorithm

shall calculate the status of the Fresh \

Recirculation door flap. The LED shall not indicate

the status of the door flap during Auto operation.

NOTE

1. The outside air intakes for the climate control

system are at the base of windscreen. Keep this

area clear from leaves and other debris.

2. The system should be used with recirculation

air mode for faster heat up and cool down,

however keeping the system in recirculation

mode, particularly with AC OFF, can cause the

windows fog up.
