NEXON

ELECTRICAL

125

DETAILED TELLTALE INFORMATION

TELL TALES

COLOR

INDICATOR

REMARKS

Diesel Pre-

Heat/Glow plug

indicator

Amber

Illuminates momentarily when ignition is switched ‘ON’ to

indicate that the glow plugs are active. It will continuously

illuminate when engine is getting preheated. Start the

engine only after the indicator goes off.

Turn Signal

Green

Indicates direction indicated by the turn signal. Blinks along

with buzzer while operating left/right turn indicator only

when ignition is switched ‘ON’.

Both telltales shall blink simultaneously when Hazard switch

is pressed.

Tick-Tock sound shall be given when any one or both the

telltales are ON.

High Beam

Blue

Illuminates when the high beam head bulbs are switched

ON or flashed.

Low Oil

Pressure

Red

Illuminates momentarily when ignition is switched ‘ON’.

Illuminates continuously if engine oil level is less than a pre-

defined minimum level. Stop the vehicle as soon as safety

permits and switch off the engine. Check engine oil level

and top-up if required. Contact qualified TATA MOTORS

assistance before starting the engine.

Battery

charging/

engine

warning

Red

Illuminates momentarily when ignition is switched ‘ON’ once

is cranked, it goes OFF.

It will continuously illuminate when there is malfunction of

charging system. Contact TATA MOTORS Authorized

Service Centre

Park Brake

cum

Low

Brake

Fluid/ABS or

EBD

Malfunction.

Red

This indicator comes ‘ON’ for approximately 4 seconds

when ignition is turned 'ON' and goes ‘OFF’. If it remains

‘ON’, it may indicate:

1. Brake fluid level is low.

2. Parking brake is applied. It shall go ‘OFF’ when it is

released.

3. Fault in ABS/EBD system.
