1.2L REVOTRON ENGINE
149
11. Remove the connecting rod bearing caps
along with bearing shells.
12. Remove gudgeon pin from the small end of
connecting rod.
13. Remove connecting rod.
NOTE
Keep each piston and gudgeon pin as a
set, when removed.
14. Using ring expander, remove piston rings
15. Insert flywheel-locking pin to lock flywheel.
16. Remove flywheel mounting bolts and then
flywheel locking pin.
