CLUTCH
3
CLUTCH PRESSURE PLATE
CLUTCH PRESSURE PLATE
PETROL
1. Max finger height of Pressure plate from clutch
mounting face
18.7 ± 1mm
2. Max permissible imbalance of clutch cover
assembly.
200 gm-mm
3. Max finger run out
0.8 at 34 mm dia
4. Clamp load (Minimum on unloading curve)
3850 N
5. Max. release load (New gauge plate)
1200 N
6. Release travel
8 + 1mm
7. Max. Wear travel
6.14 mm
8. Min. Pressure plate lift for release travel of 8 mm
1.4 mm
