4
Using TCU diagnostic tool, initiate a grid
learning procedure
Are gears engaging and disengaging freely
and grid learning is successfully executed?
Recheck the above steps
Replace parts in following
order and re-verify:
1>Valve body (MGA)
2>Gearbox
3>Entire Transmission
DTC’s confirmation:-
After rectification, clear all DTC’s and ensure the following points by referring TCU parameters using TML diagnostic tool
before handing over to customer.
Drive the vehicle through all gears in both Automatic and Manual modes
Ensure no DTC is active and Transmission Fault Lamp is OFF.
Circuit Schematic Diagram:
