14.
P0805-01: Clutch Position Sensor Circuit– Fixed Signal low Level
Overview:
ISO Code
P0805-01
Customer Symptom
Transmission Fault Lamp ON,
Loss of power while driving.
Engine not cranking
Engine stalling at low vehicle speeds
No gearshift
Fault Effects (On Vehicle)
Transmission going automatically to neutral while driving.
Engine not cranking
Engine stalling at low vehicle speeds
No gearshift
No EOL self-tuning.
Lamp Status (If Any)
Transmission Fault Lamp ON
Fault Detection Condition
This fault gets detected after Ignition On when the Engine is not cranking and
Sensor & battery Supply voltage is in proper range and a low value (no edges)
of the signal is detected for a timeout.
Normal Operating
Condition
Clutch Position signal will be in a valid range corresponding to the total travel of
the Clutch actuator between fully open and closed positions. Signal has valid
period and duty cycle.
Probable Trouble Area
Harness or connector damage/short, Sensor loose/damage/short, TCU internal
damage
Healing Condition
50 milliseconds after valid sensor signal
Component Details:
The Clutch Position sensor is PWM type sensor which outputs a signal duty cycle in proportion to the Clutch actuator position.
Preliminary Checks:
1) If this DTC occurs in combination with DTC P1852, refer remedy for P1852.
2) Loose/ Damaged TCU system connector (12 pin).
3) Check for any visible damage to TCU pins, clutch sensor and its pins.
4) Check correct fitment of ground cable connections on vehicle chassis.
Trouble Shooting:-
On first occurrence, clear the DTC and drive the vehicle for 2-3 kms, read the DTC again. On fault confirmed again, follow
below steps.
Step Checks
IF YES
IF NO
1.
Is there any rust/oxidation/pin back out
observed on 12 pin system connector pins 1, 8
&12.
Clean the Rust or repair
or replace
Go to Step 2
2.
Is there wiring harness electrical continuity
between 12 pin system connector pins 1,8
&12.toSensor connector pins 2,1 &3?
Go to Step 3
Establish continuity by
rectifying harness
connections as per the
circuit schematic
3.
Are there any pins damaged at Sensor
Connector?
Replace the system
wiring harness.
Go to step 4
4
Are any Sensor Signal Pins Short circuited to
GND/Battery?
Repair the harness as per
the schematic
Go to Step 5
5
Fault Still Persists?
Replace Sensor, if fault
persists ReplaceTCU
Follow the steps again for
reconfirmation
DTC’s confirmation:-
