ELECTRICAL
54
1.10 POWER SOCKETS
One power sockets of 12V DC-10 amps each are
provided as shown in these can be used for
connecting loads up to 10A maximum. To use this
socket, open the cap first.
1. Front power socket
2. Rear power socket
REMOVAL AND REFITMENT
1. Remove the bezel holding Power socket
2. Pry out Socket holder assembly from bezel.
3. Remove electrical connections from power
socket
4. Pry out the power socket.
