1.2L REVOTRON ENGINE
37
Engine Timing
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Fixed Blade
2 Sprocket Crankshaft
3
Hex Pivot Bolt for Chain Guide
(Movable)
2.5
4 Chain
5
Hex Bolt, Camshaft Bearing Cap
(Exhaust Camshaft VVT )
•
6.0 ± 0.5
6 Hex Fl Bolt M6x25 (2 Qty)
1.0
7 Cam Guide Valve
8
Hex Bolt (Intake Camshaft VVT)
•
6.0 ± 0.5
9 Controller Assy, Valve Timing
10 Variable Cam Timing
11 Tensioner Guide Rail
12 Hex Flange Screw M6 x14 (2 Qty)
1.0
13 Hex Flange Screw M6X30 (2 Qty)
1.0
14 Tensioner
Note:-
•
This Symbol indicates critical tightening torque.
