1.2L REVOTRON ENGINE
27
Cylinder Head-B
Note:-
•
This Symbol indicates critical tightening torque.
No.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TORQUE
(Kgf.m)
1 Lock Half (12 Qty.)
2 Valve Spring Retainer (12 Qty.)
3 Spring (Valve) (12 Qty.)
4 Spring Seat (12 Qty.)
5 Hollow Dowel (2 Qty.)
6 Orifice For Oil Gallery (2 Qty.)
7 Core Plug
8 Valve Guide Seal (12 Qty.)
9 Valve Guide (12 Qty.)
10 Valve Seat Exhaust (12 Qty.)
11 Exhaust Valve: Tc (6 Qty.)
12 Gasket, Cyl Head
13 Intake Valve: Tc (6 Qty.)
14 Core Plug
15 Plug Mc10x1
16 Cylinder Head
17 Washer (8 Qty.)
18
Bolt, Cylinder Head Torx M10x1.5 (8
Qty.)
•
1) 4+0.5
2) 185° ± 5°
19 Core Plug
20 Spark Plug (3 Qty.)
21 HLA RFF Assy. (12 Qty.)
