Intake Manifold and Fuel Injection System
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Nut (Fip) (For Fip Gear) M14x1.5
5.0
02
Timing Gear (Fip)
03
Cap Screw M6x16
04
Hex. Bolt (M8x75.5) (Qty. 3)
2.7 + 0.3
05
HP Pump
06
Assy. Fuel Pr. Line (Pump To Rail)
*
2.5 with
sleeve or
3.0 without
sleeve
07
Hex. Flange Screw M8x12
08
Hex. Flange Screw M6x12
09
Clamp
10
Cap Screw M8x22 (Qty. 4)
2.0 + 0.3
11
Intake Manifold
12
Flanged Clinch Nut (Qty. 2)
2.0 + 0.3
13
Stud C M8x30 (Qty. 2)
14
Hex. Flange Bolt M8x38 (Qty. 3)
2.0 + 0.3
15
Assy Fuel Rail.
16
Fuel Injector (Qty. 4)
17
Pin (Injector Claw Support) (Qty. 4)
18
Injector claw (Qty. 4)
19
Spherical. Washer (Injector Claw) (Qty. 4)
20
Hex. Flange Bolt M8x45 (Qty. 4)
2.9 + 0.3
