ELECTRICAL
105
For km/l setting, the indicated maximum value
of INST FE is 30 km/l. No more than 30 shall be
indicated on the display even if the actual INST
FE is higher than 30 km/l.
For MPG setting, the indicated maximum value
of INST FE is 80 MPG. No more than 80 shall
be indicated on the display even if the actual
INST FE is higher than 80 MPG.
6
Clock
Indicates current time in 12 Hrs mode.
Note: User can change the clock time using SET
and MODE buttons.
Whenever the battery terminals or related fuses
are connected User must reset the clock time.
This feature is available when ignition switch is in
ON position.
7
Outside Ambient
Temperature
Displays outside ambient temperature in units
°C or °F.
Resolution: 1 °C or °F
Note:
User can change the Temperature unit using
SET and MODE buttons and °F is applicable for
Export variant only.
The temperature sensor is in the front bumper
of the vehicle, therefore the temperature
reading can be affected by heat reflection from
the road surface, engine heat and the exhaust
from surrounding traffic. This can cause an
incorrect temperature reading when speed is
under low speeds or when stopped.
If display shows ‘- - ‘, take your car to TATA
authorized service Centre.
8
Service reminder
Indicates the number of days or kilometers
remaining for next service at every ignition ON
for few seconds if service is due.
If service is overdue, DIS shall display 0 km or
0 days and spanner symbol shall blink at every
ignition ON for few seconds.
DIS shall indicate Spanner symbol as
continuously ON when service is overdue.
When Service reminder warning appears, take
your vehicle to Authorized TATA MOTORS
service station.
Note1:
Take vehicle to Authorized service station only
for servicing.
Note2:
The service reminder through instrument cluster
is just for an indicative purpose. Please refer the
Maintenance and Service section in owner’s
manual for extensive information on service
schedules.
