CLUTCH
27
3.1.2.3.3 CLUTCH HYDRAULIC SYSTEM COMPONENTS
ITEM
DESCRIPTION
01
Assy. High Pressure Line
02
Clamp
03
Corrugated Tube Slit 5mm
04
Edge Clamp
05
Peak Torque Limiter
06
Hydraulic Adapter (For CSC)
ITEM
DESCRIPTION
07
Concentric Slave Cylinder
08
Hexagonal Flange Nut AM8
09
Control Mounting Bracket
10
Bayonet Adapter with Stud
11
Assy. Clutch Master Cylinder
12
Low Pressure Line
13
Spring Band Clamp
