ENGINE
16
Lubrication System Components :
ITEM
NO.
DESCRIPTION
NO REUSE
SEALANT
LUBRICATION
TIGHTENING
TORQUE
(kg-m)
01
Gasket (Oil Pump)
02
Assembly Oil Pump
03
Oil Seal
04
Hex FL Screw M6X20 (Qty – 8)
1
+0.2
05
Gasket
06
Hex FL Nut BM8 (Qty – 2)
2.5
±0.2
07
Assembly Strainer
08
Pipe Union Bolt (For Oil Feeder and Boost
Sensor Line)
1.8
±0.2
09
Sealing Washer
10
Gasket TC to Oil Return Tube
11
Assembly Tube Turbo Oil Return
12
Hex FL Screw M6X18 (Qty – 4)
1
+0.2
13
Assembly Oil Feeder Line (Cylinder Head
to Turbocharger)
14
Hex Collar Screw (For Nozzle Piston
Cooling) (Qty – 4)
1
+0.2
15
Piston Cooling Nozzle
16
Gasket (Piston Cooling Nozzle)
17
Assembly Oil Filter
Hand turn
until filter
contacts
base then
turn ¾
turns
18
Adaptor Bolt (Oil Filter Mounting)
19
Assembly Oil Cooler
20
Adaptor (Oil Filter Mounting)
21
Oil Pressure Switch
22
Hex FL Screw M8X25 (Qty – 3)
2
+0.3
23
Gasket (Oil Filter Adaptor to Crankcase)
