SUPPLEMENTARY RESTRAINT SYSTEM (SRS)
2
24 SUPPLEMENTARY RESTRAINT SYSTEM
(SRS)
24.1 TIGHTENING TORQUES
SR.
NO DESCRIPTION FASTENER
TIGHTENIG
TORQUE (Kg-m)
LOCATION
1
Air Bag ECU
mounting
Hex flange
nut AM6
0.95
2
Clock Spring
mounting
Flange
screw
C-ST 4.2X13
0.18
3
Front impact
sensor mount-
ing
Hex flange
bolt M6X25
0.4 – 0.6
4
Side impact
Sensor mount-
ing
Hex flange
bolt M6X25
0.4 – 0.6
