ENGINE
83
G. Exhaust System :
Exhaust System Layout :
Sr. No. Description
1
Closed Coupled Catcon Assembly
2
Front Pipe Assembly
3
Middle Pipe Assembly
4
Pre-Silencer Assembly
5
Main Silencer Assembly
6
Rubber Hanger
7
Assembly Twin Pipe with Post
Silencer
8
Intermediate Pipe Assembly
The exhaust system of TATA EAGLE consists of
a Closed Coupled Catalytic Converter, in order to
reduce the exhaust emission, a pre-silencer, a
main silencer and a twin pipe with post silencer.
The exhaust pipes are supported using rubber
hangers. Flange joints are provided at each
component to accommodate removal of each
component individually.
The Closed Coupled Catalytic Converter is
provided to reduce the exhaust emission, whereas
the silencers are provided to dampen the sound of
the exhaust gases coming out of the engine.
