77.

P1905-02: Clutch System Clutch locked

Overview:

ISO Code

P1905-02

Customer Symptom

Transmission Fault Lamp ON,

No gearshifts,

sudden shift to neutral while driving

Fault Effects (On Vehicle)

No gearshifts,

sudden shift to neutral while driving

Lamp Status (If Any)

Transmission Fault Lamp ON

Fault Detection Condition

This fault gets detected after Ignition On in engine running

condition if a sudden clutch locked open is detected during

clutch command.

Normal Operating Condition

TCU monitors correct clutch response during clutch control

phase.

Probable Trouble Area

Clutch Electro valve / TCU / Clutch

Healing Condition

Fault is cleared on next ignition Power ON

Component Details:

In an AMT system, the clutch is electro-hydraulically controlled by the TCU.

Preliminary Checks:

1) Loose/ Damaged Valve body and TCU mountings.

2) Check for damage or back out of pins at TCU connector.

3) Check visibly for kit Oil leakage and ensure with diagnostic tool that kit oil pressure is in range 38 - 51 bar

4) Check for mechanical damage to the clutch housing, clutch actuator mechanical fitments

5) Check correct fitment of ground cable connections on vehicle chassis.

Trouble Shooting:-

Step Checks

IF YES

IF NO

Check the clutch assembly and AMT clutch

lever interface for mechanical damage,

stuck particle, lubrication loss etc?

Go to Step 2

Rectify/replace the

component

Check clutch electrovalve electrical

connections by following same procedure

as for DTC P0900. Are electrical

connections OK?

Go to Step 3

Establish continuity by

rectifying harness

connections as per the circuit

schematic

Using TCU diagnostic tool, initiate clutch

and confirm that it

changes from engaged (~xxx mm) to

disengaged (yyy mm) position.

(Alternately visibly check the clutch lever

movement with actuation command.)

Is the clutch engaging and disengaging

freely?

Recheck the above steps

Replace the valve body

(Mechatronic gear Actuator),

if fault persists then Replace

Kit

the following points by referring TCU parameters using TML diagnostic tool

before handing over to customer.

Drive the vehicle through all gears in both Automatic and Manual modes

Ensure no DTC is active and Transmission Fault Lamp is OFF.

Circuit Schematic Diagram:
