53.
P0750-02: Gear 1 electro valve Short to supply
Overview:
ISO Code
P0750-02
Customer Symptom
Transmission Fault Lamp ON, sudden shift to neutral while
driving, vehicle stuck in Gear, Vehicle not cranking
Fault Effects (On Vehicle)
sudden shift to neutral while driving, vehicle stuck in Gear,
Vehicle not cranking
Lamp Status (If Any)
Transmission Fault Lamp ON
Fault Detection Condition
This fault gets detected after Ignition On when Gear 1
electrovalve is commanded OFF and a short to supply is
detected on the valve.
Normal Operating Condition
TCU does not detect short to supply
Probable Trouble Area
TCU mountings/ valve body damage / Electro valve / TCU
Healing Condition
50 milliseconds after valid detection of healed condition
Component Details:
The Gear 1 electro valve is a pressure control solenoid valve which drives linear motion of the gear engage actuator in one
direction. This component is mounted on the valve body and makes internal electrical contact with the TCU.
Preliminary Checks:
1) Loose/ Damaged Connections between Electro valve and TCU.
2) Loose/ Damaged mechanical fitments of TCU (TCU to valve body mounting).
3) Check correct fitment of ground cable connections on vehicle chassis.
Trouble Shooting:-
Step Checks
IF YES
IF NO
1
Unmount and remove the TCU from the valve body. Inspect
the condition of the Gear 1 Electrovalve(EV1) (refer fig
below).Check for electrovalve pins damaged/bent/shorting
to other pins. Is the Valve or valve pins visibly
undamaged?
Go to Step 2
Replace the
electrovalve/Valve
Body.
2
Inspect the Gear 1 Electrovalve connector on TCU main
board (refer fig below) for loose fit/disconnection/pin
damage/ short to other pins. Is the Electrovalve connected
properly?
Go to Step 3
Fit the TCU to
valve body back
ensuring proper
contacts.
If TCU side
connector damage
then replace the
TCU.
3
If Problem persists, Replace the valve body and then if still
persists, replace TCU
-
After rectification, clea
the following points by referring TCU parameters using TML diagnostic tool
before handing over to customer.
Drive the vehicle through all gears in both Automatic and Manual modes
Ensure no DTC is active and Transmission Fault Lamp is OFF.
