TIAGO

HVAC

6. Loosen and remove two mounting screws and

take out the resistor.

7. Remove the electrical connection of actuator.

8. Loosen and remove two mounting screws and

Remove the recirculating actuator.

9. Remove the electrical connection of sensor

10.Remove the sensor.

! CAUTION

Care needs to be taken while removing the thermo-

sensor avoid any damage to the thermosensor.

11.Loosen four fasteners of filter.
