-Short to Supply or open circuit on TCU
-Sensor GND loss
-Sensor supply loss
-Loose mechanical
fitment of Sensor
-Loose or damage or
short circuit internally
-TCU internal damage
14
P0805-
01
Clutch Position Sensor Circuit
Fixed Signal low Level
-Short circuit to GND on Sensor
-Short circuit to GND on TCU
- Loose mechanical
fitment of TCU
-Loose mechanical
fitment of Sensor
-Loose or damage or
short circuit internally
15
P0805-
03
Clutch Position Sensor Circuit
Period Error
-Sensor Problem
-Sensor damage
- TCU internal damage
16
P0805-
05
Clutch Position Sensor Circuit
PWM Duty high
-Sensor problem
-Sensor damage
- TCU internal damage
17
P0805-
04
Clutch Position Sensor Circuit
PWM Duty low
-sensor Algorithm Error (sensor problem,
magnet lost)
-Sensor damage
- TCU internal damage
18
P1852-
02
Clutch Position/Hydraulic
Pressure Sensor Wrong
supply voltage Vbatt Error
-TCU damage
-Short to V supply or open circuit on
Sensor supply
- Loose mechanical
fitment of TCU
-Loose mechanical
fitment of Sensor
-Loose or damage or
short circuit internally
-TCU internal damage
19
P1852-
01
Clutch Position/Hydraulic
Pressure Sensor Wrong
supply voltage GND Error
-TCU damage
- Short circuit to GND On Sensor supply
- Short circuit to GND On TCU
- Loose mechanical
fitment of TCU
-Loose mechanical
fitment of Sensor
-Loose or damage or
short circuit internally
-TCU internal damage
20
P0932-
02
Hydraulic Pressure Sensor
Circuit Signal over Max
Threshold
-Short to V supply or open circuit on
Sensor signal
-Short to Supply or open circuit on TCU
-Sensor GND loss
-Sensor supply loss
- Loose mechanical
fitment of TCU
-Loose mechanical
fitment of Sensor
-Loose or damage or
short circuit internally
-TCU internal damage
21
P0932-
01
Hydraulic Pressure Sensor
Circuit Signal under Min
Threshold
-Short circuit to GND on Sensor
-Short circuit to GND on TCU
- Loose mechanical
fitment of TCU
-Loose mechanical
fitment of Sensor
-Loose or damage or
short circuit internally
-TCU internal damage
22
P0932-
07
Hydraulic Pressure Sensor
Circuit Wrong value sensor
Sensor damage
- Loose mechanical
fitment of TCU
-Loose mechanical
fitment of Sensor
