TIAGO

TIAGO AMT Gasoline

DTC Troubleshooting Guide

Version: 2.0

Date: 06-06-2016

Author: Sathi/Anupama

Page: 375 of 424

TATA MOTORS Ltd.

This document must not be used in any way, such as copying and redistributing to third parties, without the consent of author.

After rectification, ensure the following points using TML diagnostic tool before handing over to customer

a) DTC should not be in ECU fault memory.

Connector View & Information: -

IPC ECU side connector diagram

ECU Pin assignment:-

Description

ECU pin

CAN_H chasis

CAN_L chasis

Battery

Ignition input

Battery ground
