TIAGO

INSTRUEMENT CLUSTER

TELL TALES

COLOR

INDICATOR

REMARKS

Diesel Pre-

Heat/Glow plug

indicator

Amber

indicate that the glow plugs are active. It will continuously

illuminate when engine is getting preheated. Start the

engine only after the indicator goes off.

Turn Signal

Green

Indicates direction indicated by the turn signal. Blinks along

with buzzer while operating left/right turn indicator only

High Beam

Blue

Illuminates when the high beam head bulbs are switched

ON or flashed.

Front Fog

Green

Illuminates when front fog bulb

Low Oil

Pressure

Red

1. Illumi

2. Illuminates continuously if engine oil level is less than a

pre-defined minimum level. Stop the vehicle as soon as

safety permits and switch off the engine. Check engine oil

level and top-up if required. Contact qualified TATA

MOTORS assistance before starting the engine.

Battery

charging/

engine warning

Red

once

is cranked, it goes OFF.

It will continuously illuminate when there is malfunction of

charging system. Contact TATA MOTORS Authorized

Service Centre

Park Brake

cum

Low

Brake

Fluid/ABS or

EBD

Malfunction.

Red

once

engine is cranked, it goes OFF.

2. When brake fluid level is low.

3. When park brake is applied and goes OFF when it is

released

4. When ABS/EBD system has a fault.

Seat belt

warning

Red

It will flash along with buzzer for 6 secs when ignition is

switched

to flash until the car exceeds a speed of 20 kmph. After

that, it will remain continuously ON along with a buzzer that

will be audible for approx. for100 secs. Then buzzer goes

OFF but the indicator continues to remain ON until seat

belts are fastened.
