BRAKES
44
5. Disconnect vacuum hose from brake booster.
6. Loosen coupling nuts and disconnect hydraulic
lines attached to TMC.
7. Remove mounting fasteners of TMC and take
it out.
8. Remove brake pipes from mounting clamp on
crash member so that brake booster can be
easily taken out.
9. Release both clevis clips securing brake
booster push-rod to brake pedal.
10.Loosen clutch master cylinder bolts (For
QUADRAJET).
