ELECTRICAL
95
TELL TALES
COLOR
INDICATOR
REMARKS
Malfunction
Indication Bulb
Amber
1. Illuminates momentarily when ignition is switched ‘ON’
once engine is cranked, it goes OFF.
2. It remains ‘ON’ if there is malfunction in Engine system.
Engines performance deteriorates while it is running.
Avoid high speeds and Contact TATA MOTORS
Authorized Service Centre for rectification.
Check Engine
Amber
1. Illuminates momentarily when ignition is switched ‘ON’
once engine is cranked, it goes OFF.
2. Illuminates continuously if a fault arise in Engine
Management System. Contact TATA MOTORS Authorized
Service Centre.
Immobilizer
Red
1. Illuminates when the system disables engine start if the
original key is not used.
2. Bulb blinks: vehicle is in immobilized condition when key
is not inserted.
3. Bulb ON: Problem with key/system. Contact TATA
MOTORS Authorized Service Centre.
Water in fuel
Amber
1. Illuminates momentarily when ignition is switched ‘ON’
once engine is cranked, it goes OFF.
2. Illuminates continuously if excess water is accumulated
in the fuel filter. Contact TATA MOTORS Authorized
Service Centre to drain the water immediately to avoid
serious damage to the fuel injection system.
Speed Limit
bulb
This symbol comes ON when vehicle speed is more than
120 kmph. This symbol blinks and audible buzzer sounds
simultaneously when Vehicle Speed is more than 120
kmph. At this stage, reduce the vehicle speed.
Diesel
Particulate
Filter bulb
This symbol lights up when the ‘IGN’ is turned ‘ON’ and
should go ‘OFF’ after the engine starts. This symbol
comes ON when Diesel Particulate filter in exhaust system
is malfunctioning. At this stage, take the car to the nearest
Authorized Service outlet.
DRL Bulb
This symbol lights up when the ‘IGN’ is turned ‘ON’ and
should go ‘OFF’ after 4 seconds. This symbol comes ON
when the Day Time Running bulb is ‘ON’.
CNG Bulb
This symbol lights up when the ‘IGN’ is turned ‘ON’ and
should go ‘OFF’ after 4 seconds. This symbol comes ON
when CNG fuel mode is activated.
AMT fault
indicator
When ignition is turned ‘ON’, this symbol comes ‘ON’ for
four seconds and goes ‘OFF’. This symbol will continue to
remain 'ON' or will come 'ON' after Ignition On precheck if
there is a problem in the AMT system.
