ELECTRICAL

122

Door Relay

These parameters give the following information

Information about the door relays which controls the window operation (up/down)

The status of relays for all four windows in the vehicle are showed with Active /Inactive and as shown in

the below figure.

Technician can actually know whether corresponding relay is operating correctly or not.
