SAFARI

486 PL ENGINE

Install crank shaft front oil seal using drift

Pt. No. 2654 5890 0303. Fig. 151

Fit crank case front cover with new gasket. Tighten

screw to specified torque. Fig. 152

Fit oil sump with new gasket. Tighten mounting

screws to specified torque. Fig. 153

Install wood ruff keys in position on crank shaft

front end.

Install by slight tapping crank shaft gear. Fig. 154

Fig. 154

Fig. 153

Fig. 152

Fig. 151
