486 PL ENGINE P
Ensure fitment of rubber 'O' ring in fuel pressure
regulator. Fig. 122
Press pressure regulator and tighten its mounting
bolts.
Fig. 123
Fig. 122
'O' ring
Fig.124
CONNECTION
PIPE
Press fuel rail injectors in the inlet manifold and
tighten rear mounting nut. Fig. 123
Fit flexible rubber pipe from fuel pressure regulator
to inlet manifold.
Fit the oil vapour (blow-by) return hose and fit rubber
connector hose to throttle assembly and then fit
connection pipe. Fig. 124
