SAFARI

1154 / 1526

G
8
GENERAL
5. AGGREGATE NUMBERING SYSTEM :
Transfer Case Number Front Axle Number
Chassis Number Engine Number Rear Axle Number
Gear Box Number
Fig. 15 Locations of Aggregate Numbers
A. FRAME
Aggregate number for Fame consists of Five barrels
X XXX XX X XXXXX
Barrel 1 : Indicates basic model, T for Safari
Barrel 2 : Indicates variation in basic model as below
405 - For Safari, 2650mm WB, Diesel 4 x 2
406 - For Safari, 2650mm WB, Diesel 4 x 4
407 - For Safari, 2650mm WB, Petrol 4 x 2
408 - For Safari, 2650mm WB, Petrol 4 x 4
Barrel 3 : Indicates year of production
2002 - XZ
2003 - WZ
2004 - VZ
2005 - UZ
2006 - TZ
2007 - SZ
2008 - RZ
2009 - QZ
Barrel 4 : Indicates plant location
8 for J Block, Pune
Barrel 5 : Indicates cumulative serial number of
frame.
B. ENGINE :
Aggregate number for Engines consists of six / seven
barrels
XXXXXXX XX X X XX X XXXXX
1 2 3 4 5 6 7
Engine model Engine No.
Barrel 1 : Indicates engine model like for example
483 DLTC / DICOR / 486 PL.
Barrel 2 : Indicates variation in basic model of
engine i.e.
For 483 DL TC - 55 Euro III emission norms
For DICOR - 07 BS-III emission norms
Barrel 3 : Indicates ‘L’ for LHD application only.
