3 CYL PETROL ENGINE
55
Installation:
1. If reusing the spark plugs, clean using a
brush and a solvent prior to installation.
2. Verify the electrode gap is between 0.7 to
0.8 mm. Adjust the gap necessary.
3. Carefully hand-thread the spark plug into the
cylinder head. Do not cross-thread the spark
plug into the cylinder head.
4. Once the spark plug has seated, use the
M16 socket to torque the spark plug to 2 -2.5
kgfm.
5. Connect the correct spark ignition coils to
the spark plug. Verify the cable terminal
makes a firm connection with the top of the
spark plug.
6. Repeat the procedure for the remaining
spark plugs.
