3 CYL DIESEL ENGINE
90
8. Remove the drain bolt (1) from the transaxle.
Drain the transaxle oil from the vehicle.
9. Recover A/C gas and oil, using recovery unit.
10. Disconnect and remove the auxiliary tank and
hoses from engine.
11. Remove the coolant hoses from the engine
and heater core.
12. Remove all the hoses connected between
radiator and engine.
13. Remove the air filter assembly and intake
system hoses from the engine.
14. Disconnect and remove vacuum hose
connected between brake booster to vacuum
pump.
15. Disconnect the fuel supply connection to
Engine by relieving the fuel pressure.
