ENGINE2.2LDICOR
SL.
DESCRIPTION
NO.
01 ASSY.CRANKSHAFTWITHCYL.PIN.-NORMAL
02 D.G.BALLBRG.(6202-2RS1/C3HT22B)(SKF)
03 CYLINDRICALPIN
04 FLYEHEEL(INCREASEDINERTIA)
05 RINGGEAR
06 SET-LOCKINGPLATE
07 HEX.BOLT(FLYWHEELMOUNTING)
08 CRANKSHAFTGEAR(SINTERED)
09 KEY
10 FRICTIONPLATE(ONCRANKSHAFT)
11 ASSY.VIBRATIONDAMPER
12 HEX.BOLT-(ONCRANKSHAFT)
13 WASHER(CRANKSHAFTGEAR)
16 BOLT(CONNECTINGROD)
SL.
DESCRIPTION
NO.
17 FLANGE NUT(CON. ROD)(SUNDARAM
FASTENERS)
19 SETPISTONWITHOUTRINGSGRADEA(IP)
19 SETPISTONWITHOUTRINGSGRADEB(IP)
19 SETPISTONWITHOUTRINGSGRADEC(IP)
120 SETPISTONRINGS(IP)
14 SET-M.B.SHELL(UPPER/LOWER)
18 SET-CON.RODBRG.SHELL(UPPER/LOWER)
21 SET-THRUSTWASHER(UPPER/LOWER)
22 ASSY.FLYWHEELWITHRINGGEAR(INCREASED
24 ASSY.FLYWHEELWITHRINGGEAR+CYL.PIN
26 ASSY.CONNECTINGRODWITHBUSH
