SAFARI

ELECTRICALS

5. FUSES & RELAYS

Location of Fuses, Relays &

Controllers : Fig. 1 & 2

1. Engine compartment Relay Fuse Bank

Assy. Fuse Box Relay Cover 4DL (upgrade)

Domestic / Export

2. Cabin compartment Relays / Controllers under

Driver’s Seat

Assy. Relay Cover (Under Front RH Seat) Diesel

/ Petrol

3. Cabin compartment Relays / Controllers under

co-driver’s Seat

Assy. Relay Cover (Under Front LH Seat) Diesel /

Petrol

4. Cabin compartment Fuse Bank

CDB Cabin Cover Sticker 4DL / 4PL Upgrade

Export / Domestic

5. Cabin compartment Relays / Controllers under

glove box

Assy. Cover (Control Units)

Fig. 1
