SAFARI

1423 / 1525

ELECTRICALS
2
2. CIRCUIT DIAGRAM SYMBOLS
SYMBOL DESCRIPTION SYMBOL DESCRIPTION SYMBOL DESCRIPTION
GROUND
OR
EARTH
DIODE
SINGLE WAY
SWITCH
TWO WAY
SWITCH
FUSE
RESISTOR/
POTENTIOMETER
VARIABLE
RESISTOR
THERMISTER
CIGARETTE
LIGHTER
HEATER
DEFROSTER
SOLENOID
VALVE
ELECTRONIC
CONTROLLER
MAGNETIC
CLUTCH
CABLE
JOINT
CROSSOVER
WITH JOINT
CROSSOVER
WITHOUTJOINT
LAMP / BULB
MOTOR
WIPER
MOTOR
W/SWASHER
MOTOR
ALTERNATOR
BLOWER
MOTOR
COUPLER
FAN
BATTERY
TEMP.
SENSER
DIGITAL
CLOCK
HORN
ELECTRONIC
CONTROLLER / RELAY
BASE
VIEWFROM
CABLE ENTRY
MINIATURERELAY
t0
THERMOSTAT
SWITCH
1,6 4,9
3,8 5,10
1 2 3
4
5
6 7 8
9
10
M
LOCK ACC. IG.
START
STEERING LOCK CUM IGN.SWITCH
M
M
G
3
M
(A)
(D)
(J)
(E) (C)
(B)
0t
BUZZER
J B C
CDA
H E F
