4 DLT ENGINE
U
niformly and evenly unscrew oil sump mounting
screws and remove oil sump. Refer figure 43.
U
nscrew and remove oil pump mounting bolts.
T
ilt oil pump towards front end and remove chain from
oil pump drive sprocket gear.
R
emove oil pump. Refer figure 44.
R
emove ladder frame by removing setscrews. Refer
figure 45.
R
emove crank case front cover with crankshaft front
oil seal. Remove oil seal. Refer figure 46.
R
emove oil pump drive chain.
Fig. 44
Fig. 45
Fig. 46
Fig. 43
