SAFARI

1348 / 1588

ENGINE
149
01'
ASSY.FIP
01-a HEXFLANGENUT02'
FIPGEAR
03'
GASKET
04'
SUPPORT
05'
GASKET
06'
SUPPORT
07'
ASSY.FUELRAIL
08'
RAILMOUNTINGSPACER
09'
SETASSY.HP LINES
09-a ASSY.HP LINES09-b ASSY.HP LINE (RAIL TO
INJECTOR
09-c ASSY.HP LINE (RAIL TO
INJECTOR
09-d ASSY.HP LINE (RAIL TO
INJECTOR
09-e ASSY.HP LINE (RAIL TO
INJECTOR
10
SET BACK LEAKHOSES
10-a HOSE BACK LEAK10-b HOSE BACK LEAK10-c HOSE BACK LEAK10-d HOSE BACK LEAK11
HEXSCREW
12
HEX.BOLT
13
HEXSCREW
14
HEXSCREW
15
T- CONNECOTR
16
ASSY.INJECTOR
17
CLAW
18
SEALINGWASHER
19
SPH.WASHER
20
HEXFLANGEBOLT
SR.
Description
NO.
HIGH PRESSURE CIRCUIT AND BACK LEAK
NOTE : *INDICATES IF REMOVED NOT BE REUSED
EXPLODED VIEWS
