ENGINE

142

01

ASSY.CYL.HEAD

WITHVALVES

02

CYLINDERHEADGASKET

03

HEXCOLLAR BOLT

01-a

ASSY.CYL.HEADW/O

VALVES

01-a-a CYLINDERHEAD

01-a-b PLUGMC

01-a-c PLUGMC

01-a-d SEALINGPLUG

01-a-f

VALVESEAT

RING-INLET-NORMAL

01-a-g VALVESEAT

RING-EXHAUST-NORMAL

01-a-h VALVEGUIDE INLET STD

01-a-i

VALVEGUIDE-EXHAUST

01-c

VALVEGUIDE

SEAL-INLET

01-b VALVEGUIDESEAL-EXH

01-e

VALVE SPRING (INNER)

01-d VALVE SPRING (OUTER)

01-h VALVE SPRINGWASHER

01-f

LOCKRETAINER

VALVESPRING

01-g VALVE SPRINGLOCK

HALF

01-k

VALVE-INLET

01-j

VALVE-EXHAUST

ASSY. CYLINDER HEAD VALVES

SR.

NO.

Description

EXPLODED VIEWS
