SAFARI

GEAR BOX G-76

Loosen nuts and removeAssembly gear case cover -

Front. Take out main shaft & Counter shaft bearing

play adjusting shims from cover and keep them

properly.

Ref Fig. 25

Loosen and take out reverse Idler shaft mounting screw

from housing - Front half. Ref Fig. 26

Pull out plug and then take out detent along with spring.

Loosen the reverse idler mounting screw. Ref Fig. 27

Fig. 25

Fig. 26

Fig. 27
