ENGINE2.2LDICOR
168
Sr.
Fault for
Pin
Fault
Service
MILLamp
Fault code
Symptoms
Tocheck
To rectify
No
the sensor
Description
Lamp
9 ACC.PEDAL
-
OpenCircuit/
P0120,P1123,
1. Pedal Device connection Removeandconnectagain
Looseconnector
P0222,P0122
224
Short circuit to -ve
P1123,P0122,
Maxspeed4000rpm 2.Electrical wiring from
Terminal backout, wire open
P0192,P0642
ECUto Pedalsensor
circuit & short circuit
225
Short circuit to -ve
P1121,P0122
3.ECUconnection
Connect properly
226
Short circuit to -ve
4.PedalDevicemal
ChangeDevice
functioning
210
Short circuit to -ve
P1101,P1123,
P0102,P0237,
P0222,P0652
213
Short circuit to -ve
P1121,P0122
214
Short circuit to -ve
-
Track1-SignalLow
P0122
-
Track1-SignalHigh
P0123
-
PedalSensorfault,
P0120
Track1VEXT
-
Track2-SignalLow
P0222
-
Track2-SignalHigh
P0223
-
PedalSensorfault,
P1220
Track2VEXT
-
Sensorfaulttriggers
P0120
LimpHomemode
limp home
-
Sensorfaulttriggers
P1121
ReducedTorque
reduced torque
mode
mode
-
Pedalcorrelation
P1123
fault,Track1 over2
-
Pedalcorrelation
P1223
fault,Track2 over1
-
PEDALSTUCK,
P2299
LimpHomemode
5. Brake switch problem
Rectify / change brake switch
electrical fault
10 BRAKESWITCH
-
OpenCircuit
1. Switch connection
Removeandconnectagain
/Looseconnector
223
Short circuit to -ve
2.12Vsupplyandfuse
Supply continuity and
correspondingfuse
-
Brakeswitchsignal
P0571
3. Electrical wiring
Terminal backout, wire open
error/plausibilty
circuit & short circuit
-
Brake lightsignal
P1571/P1572
4.ECUconnection
Connect properly
fault
5.BrakeBracket,switchand Ensureproperpositioningand
setting
setting
