ENGINE2.2LDICOR
SL.
DESCRIPTION
NO.
01 H/FLSCREWM8X22TS171308.8SS8451S2-Y
02 ASSY.PIPE-COOLANTBYPASS
03 GASKET-WATEROUTLETELBOWTOBYPASSPIPE
04 ASSY.COOLANT PIPE(EGR/OIL COOLER
RETURN)
05 ASSY.CLAMP(COOLINGPIPES)
06 ASSY.CLAMPINGPLATELOWER(COOLINGPIPE)
07 HEXNUTW/COLLARM8IS7795-10SS8451S2-YH
08 RUBBERGROMMET(EGR/OILCOOLERRETURN)
09 RUBBERGROMMET(BYPASSPIPE)
10 CLAMPINGPLATEUPPER(COOLINGPIPES)
11 H/FLSCREWM8X16TS17130-8.8-SS8451S2-Y
12 RUBBERHOSE-BYPASSPIPE-THERMOSTATHSG.
13 SPR.BDCLAMP19DX12WTS17665SS8451S2-Y
15 RUBBER HOSE-EGR/OIL COOLER TO
THERMOSTAT
SL.
DESCRIPTION
NO.
16 SPR.BDCLAMP27DX12WTS17665SS8451S2-Y
18 ASSY.THERMOSTATCOMPLETE
19 GASKET
20 COVER(THERMOSTATHOUSING)
21 ASSY.THERMOSTATHOUSING
22 THERMOSTAT-88SOT
23 HEXNUTW/COLLARM8IS7795-10SS8451S2-YH
24 SEALINGWASHER14X20IS3175-CU
25 STUDAM6X20 IS18628.8SS84518C
26 .HEATERHOSE(HVACTOENG.PUMP)-2.2L
27 GASKET (THERMOSTATHOUSING)
28 SPRINGBANDCLAMP23DX12WTS17665
29 H/FLSCREWM8X22TS171308.8SS8451S2-Y
30 TEMPSENSOR2K21%BROWNCONN-ED
