1005 / 1588
118
ENGINE2.2LDICOR
SL.
DESCRIPTION
NO.
02 ASSY.CYLINDERCRANKCASEWITHM.B.CAPS
01 ASSY.INJECTOR(DELPHI)
02 INJECTORCLAW
03 HEXBOLTM8X40(INJECTORCLAW)
04 SPH.WASHER8.4IS4297-SS8400
05 GLOWPLUG(BERU)
06 CYLINDERHEAD
08 H/FLBOLTM6X40TS1713010.9SS8451S2-YH
09 STUDCM8X25IS1862-8.8-SS8451S2-Y
10 PIN,INJECTORCLAW
11 CAMSHAFT(INTAKE)
12 OILSEAL(CAMSHAFT)(SKF)
13 GEAR-CAMSHAFT—REAR
14 CAMSHAFT(EXHAUST)
15 HEX.BOLT-CYLINDERHEAD
SL.
DESCRIPTION
NO.
16 CAMSHAFTDRIVENVACUUMPUMP-VAPEC19S-
LUK
17 H/FLSCREWM6X20TS171308.8SS8451S2-Y
19 ASSY.LIFTINGHOOK
20 H/FLSCREWM8X18TS17130-8.8-SS8451S2-Y
21 WASHER-CYLINDERHEADBOLT
22 GASKET - CYLINDERHEAD - MLS(1.4THK -
REINZ)
23 LIFTINGHOOK-REAR
24 GASKET(PININJECTORCLAW)
25 GASKET-VACUUMPUMP
26 PLUGMC10X1IS9645-SS8451S2-Y
27 SETINJECTORCLAWPIN
28 CYLPIN4m6X8IS2393SS8451S2-Y
29 ASSY.CAMSHAFT(INTAKE)WITHPIN&GEAR
30 ASSY.CAMSHAFT(EXHAUST)WITHPIN&GEAR
