9 / 414
INDEX
Electrical
BOLT / ZEST
SR . NO
DESCR IP T ION
P AGE NO
01 INDEX & SYMBOLS
1
02 OPTION CODE
2
03 HARNESS AND EARTH TOPOLOGY
3 - 4
04 POWER SUPPLY
5-13
05 GROUNDINGS
14 - 18
06 STARTING AND CHARGING REVOTRON 1.2T
19
07 STARTING AND CHARGING QUADRAJET
20
08 EMS SYSTEM REVOTRON 1.2T
21- 23
09 EMS SYSTEM QUADRAJET
24 - 25
10 AMT WITH QUADRAJET
26
11 RADIATOR FAN
27
12 FUEL PUMP SYSTEM W/O INERTIA SW
28
13 FUEL PUMP SYSTEM WITH INERTIA SW
29
14 MANUAL HVAC
30
15 HVAC SYSTEM FATC
31
16 ABS 9.1
32
17 POWER WINDOWS (FRONT DOORS)
33
18 POWER WINDOWS (ALL DOORS)
34
19 CENTRAL DOOR LOCKING SYSTEM
35
20 INSTRUMENT CLUSTER
36
21 FRONT WIPER W/O BCM
37
22 FRONT WIPER WITH BCM
38
23 REAR WIPER (BCM )
39
24 HEAD LAMP SYSTEM W/O BCM
40
25 HEAD LAMP SYSTEM WITH BASE BCM
41
26 HEAD LAMP SYSTEM WITH M ID BCM
42
27 POSITION LAMP W/O BCM (BOLT)
43
28 POSITION LAMP WITH BCM (BOLT)
44
29 POSITION LAMP (ZEST)
45
30 SIDE INDICATOR W/O BCM
46
31 SIDE INDICATOR (BCM )
47
32 SIDE INDICATOR (ZEST)
48
33 STOP LAMP (WITHOUT BCM )
49
34 STOP LAMP (BCM )
50
SR . NO
DESCR IP T ION
P AGE NO
35 STOP LAMP (ZEST)
51
36 REVERSE LAMP (WITHOUT BCM)
52
37 REVERSE LAMP (BCM)
53
38 REVERSE LAMP (ZEST)
54
39 FRONT FOG LAMP WITH BASE BCM
55
40 FRONT FOG LAMP WITH MID BCM
56
41 REAR FOG LAMP (BCM)
57
42 DAY RUNNING LIGHT WITH MID BCM
58
43 CAN SYSTEM XE BOLT
59
44 CAN SYSTEM XE ZEST
60
45 CAN SYSTEM XMI BOLT AND ZEST
61
46 CAN SYSTEM XM BOLT AND ZEST
62
47 CAN SYSTEM XMS BOLT AND ZEST
63
48 CAN SYSTEM XM ABS AMT FOR BOLT AND XMA FOR ZEST
64
49 CAN SYSTEM XT BOLT
65
50 CAN SYSTEM XT ZEST
66
51 IMMOBILISER
67
52 PERIMETRIC ALARM STSEM
68
53 HEATED REAR WINDOW
69
54 EPAS SYSTEM
70
55 POWER MIRROR ADJUST
71
56 INTERIOR LIGHTING
72
57 HORN SYSTEM
73
58 POWER SOCKET FRONT
74
59 AIRBAG SYSTEM
75
60 REVERSE PARKING AID
76
61 INFOTAINMENT SYSTEM
77 - 78
62 MUSIC SYSTEM AFTER MARKET
79
63 BASE BCM
80 - 81
64 MID BCM
82 - 83
65 ACCESSORIES CONNECTOR
84
66 OBD CONNECTOR
85
67 FUSE BOX DETAILS
86
