ENGINE 1.3 QUADRAJET (75PS)
70
7. Tank Unit Supporting Bracket Removed: Photo
“Supporting Bkt. Removed.
3. Unscrew fuel tank unit cover screw and remove
cover.
4. Disconnect Tank Unit Electrical Connector From
Tank Unit.
5. Disconnect tank unit inlet and outlet Quick
Connect Couplers:
6. Remove tank unit supporting bracket fasteners.
