ELECTRICAL
102
8.10.7 HAZARD WARNING SWITCH:
FUNCTION:
Hazard warning is used in case of
breakdown especially during night and the car has
to be parked at the side of the road. This switch
can also be used when the car is operated in
adverse conditions. This switch can be operated
without Ignition ON.
LOCATION:
It is fitted on the Centre finisher.
REMOVAL:
1.Remove Center finisher assembly (Refer
body
section
).
2.Disconnect the electrical connection of hazard
warning switch.
3.Pry out the Hazard warning switch from centre
finisher.
INSPECTION:
Test the switch with a Multimeter. Clip the probe
of the multimeter to switch terminal and body
ground and check the continuity.
CONDITION
SPECIFIED
Not Pushed(OFF)
No continuity
Pushed(ON)
Continuity
If not as per specified condition, then replace the
switch.
REFITMENT
1.Locate and fit (
snap fit
) the switch in the cutout of
centre finisher.
2.Connect the electrical connection of the hazard
warning switch.
3.Fit the Center finisher assembly (Refer
body
section
).
