BRAKES
57
BRAKES
6. Insert the sliding pin into the carrier bores and
fit the sliding pin boots on to the carrier
(thick
collar end of the boot).
7. Now fit the caliper housing to the carrier in the
reverse order of removal.
NOTE
Adjust the sliding pin such that the flat end should
match caliper housing slot.
8. Tighten the pin bolt.
