SAFARI STORME MY14_VOLUME 1

632 / 1235

BRAKES
6
6.1.1.3 TIGHTENING TORQUES
SR.
NO.
DESCRIPTION FASTENER TIGHTENING
TORQUE (Kg-m)
LOCATION
1
Bleed screw
(Front)
Hex. A/F 9 0.55 ~ 0.8
Bleed screw
(Rear)
Hex. A/F 10 0.7 ~ 1.3
2
Caliper sliding pin
bolt
(Front / Rear)
Hex. A/F 12 2.2 ~ 3.2
3
Front Caliper
mounting flange
screw
M12X1.25X 42 6.8 ~ 9
Rear Caliper
mounting flange
screw
M12X1.25X 28 6.8 ~ 9
