SAFARI STORME MY14

BODY

HOOD LATCH ASSEMBLY

REMOVAL

1. Disconnect the hood release cable from the

hood latch assembly.

(For procedure refer

Bonnet latch release cable removal process in

this section.)

2. Loosen and remove mounting screws

(1) (6

Nos.),

remove mounting bolt

(2),(2 Nos.)

and

take out the finisher grill assembly.

3. Loosen and remove three mounting bolts and

separate it from the vehicle.

FITMENT

For fitment follow the reverse procedure of

removal.

HOOD LATCH

(BONNET SIDE)

REMOVAL

1. Open the bonnet.

2. Loosen and remove two mounting bolts and

take out the hood latch from bonnet end.

FITMENT

For fitment follow the reverse procedure of removal
