ELECTRICALS
90
1.2 EMS ECU CONNECTOR REMOVAL
AND RE-FITMENT ON VEHICLE:-
Removal:
1. Open the tail gate by key.
2. Pull the both side strip simultaneously (located
behind the rear seat) to fold the seat.
3. Open the parcel tray.
4. Disconnect the speaker wiring harness
connector.
5. Pull out the parcel tray from both sides of
guide bush simultaneously.
6. Remove the floor mat.
