STEERING SYSTEM
569
STEERING
SCHEMATIC OF STEERING SYSTEM
SR.NO. DESCRIPTION
1 Steering wheel
2 Steering upper column
3 Upper universal joint
4 Intermediate shaft
5 Lower universal joint or Steering gear end
universal joint
6 Steering rack and pinion assembly
7 Tie rod assembly
8 Outer ball joints
